Shurflo 12V 4009 Water Pump With Fittings (C-Tick Approved)

Product Code:

800-00022
Shurflo 12V 4009 Water Pump With Fittings (C-Tick Approved)

A fresh water pump designed with a one-piece diaphragm and internal by-pass ensuring a long life and max performance.

Product Description

Constructed for high flow demand, this updated Shurflo pump is has low noise emissions and no rapid cycling. Comes complete with 2 x 12mm barb fittings.

Features and Benefits:

  • Four Independent Pump Chambers - Quiet and smooth operation
  • Adjustable Pressure Shut Off - Fine tuning for customer specific application
  • Self priming up to 1.8 meters (6 feet) vertical
  • O-ring Check Valve Design - Long life and consistent performance
  • Adjustable Bypass - Eliminates need for accumulator tank
  • Run Dry Capability - Long life consistent performance
  • CE & C-Tick compliant

Must be installed with a filter.(see SKU 800-00300 or 800-00312)

Specifications

    • Pump
    • 10lts per minute
    • Type: 4 Chamber Diaphragm Pump
    • Ports: ½” - 14 NPSM-Male
    • Inlet PSI: 30Psi (2.1Bar) Max
    • Electrical
    • Motor: 12V DC Permanent Magnet, Intermittent Duty
    • Protection: Thermal Overload, Automatic Restart
    • Fuse: 7Amp Recommended
    • Materials
    • Housing: Polypropylene
    • Hardware: Stainless and Zinc Plated Steel
    • Net Weight: 2.3Kg
    • Dimensions: 205L x 125W x 111H (mm)
